4.3" MINI PI
+3
Elite PI TFT · EMN43-BXX

4.3" MINI PI

Made to order · lead time on request

A full-colour position indicator for car and landing. Crisp position and direction display with scrolling messages, custom graphics and digitised voice — engineered to fit existing stud patterns for fast modernisation.

Faceplate finish
Request a quote
Documentation
PDFDatasheetPDF · 1.2 MB↓PDFWiring diagramPDF · 480 KB↓PDFInstallation guidePDF · 2.1 MB↓
DisplayTFT TFT
Supply24 V DC
Resolution1024 × 600
ComplianceADA / DDA
OverviewSpecificationsWiring & installationDownloads
Overview

Premium indication, built for retrofit.

The Elite PI TFT brings full-colour position and direction indication to any car. Floor labels, directional arrows, scrolling messages and custom graphics are all driven from a single display, with optional digitised voice for ADA / DDA compliance.

Designed as a direct replacement, it mounts to existing stud patterns and accepts the signal types already on your controller — so modernisation is a swap, not a rebuild.

01
Custom graphics
Match house style, logos and floor naming.
02
Digitised voice
Multi-language arrival and passing announcements.
03
Universal inputs
Gray code, binary and serial signal support.
04
Direct fit
Mounts to existing stud patterns and wiring.
Specifications

Technical specification

DisplayTFT colour TFT
Supply voltage24 V DC
Resolution1024 × 600 px
Current draw≤ 250 mA
IndicationPosition · direction · messages
Operating temp.0 – 50 °C
Signal inputsGray · binary · RS-485
MountingFlush / surface, stud-fit
FinishStainless
ComplianceADA / DDA
AudioOptional digitised voice
Warranty5 years

Representative values — confirm against the datasheet for the selected configuration.

Wiring & installation

Connect it in minutes.

Terminal layouts and connection detail for every supported signal type are in the wiring diagram. The installation guide covers cut-out, mounting and commissioning step by step.

PDFWiring diagramTerminal & connection detail · PDFDownload ↓PDFInstallation guideMounting & commissioning · PDFDownload ↓
Wiring diagram
Documentation & downloads

Everything you need to specify and fit.

PDFDatasheetFull technical datasheet — specifications, dimensions and ordering codes.PDF · 1.2 MB↓PDFWiring diagramConnection and terminal wiring for all supported signal types.PDF · 480 KB↓PDFInstallation guideStep-by-step mounting and commissioning instructions.PDF · 2.1 MB↓PDFDimensional drawingCut-out, stud pattern and overall dimensions for fit-up.PDF / DWG · 320 KB↓
